Kia Soul III facelift (2022-2024) spoc+ ext tail fl Wiring diagram
This page shows the only wiring diagram for the component.spoc+ ext tail fl, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spoc+ ext tail fl (1 of 1)
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
B/2
B/3
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
EXT TAIL RL
GRN WIRE
GRN/ORG WIRE
HIGH MOUNTED STOP LAMP
HMSL
HOT AT ALL TIMES
ICU JUNCTION BLOCK (LEFT END OF DASH)
ICU-A
ICU-B
ICU-C
ICU-G
IPS CONTROL MODULE
IPS STOP LAMP LH
LEFT HEADLAMP
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
PNK WIRE
POSITION LAMP
RED WIRE
SIDE MARKER LAMP
SPOC+ EXT TAIL FL
SPOC+ EXT TAIL FR
SPOC+ EXT TAIL RR
SPOC+ T/SIG FRT LH
STOP LAMP RH IPS
T/SIG FRT RH
T/SIG RR LH
T/SIG RR RH
T/SIG TELLTALE LH
T/SIG TELLTALE RH
TURN LAMP
W/ LED
W/O LED
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 4) -> SPOC+ EXT TAIL FL
