Kia Soul III facelift (2022-2024) spi to usb Wiring diagram
This page shows the only wiring diagram for the component.spi to usb, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spi to usb (1 of 1)
AIR BAG
AIR BAG (+) IN
ALT L IN
AMP
BACKLIGHT DRIVER
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
D OUT
DETENT OUT
EEPROM
FUEL
GRIP CONTROL SW (-)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-E
IGN
ILL (-) OUT
IND
INSTRUMENT CLUSTER
LDO
MEMORY
MICOM
MULTIMEDIA FUSE
N OUT
OIL PRESSURE SWITCH
OIL PRESSURE SWITCH-IN
ORG/ WIRE
P OUT
PNK WIRE
PNK/BLK WIRE
R - OUT
RED WIRE
S OUT
SEG LCD
SENDER
SIG
SIGNAL 1 GND
SPEAKER
SPEED OUT
SPI TO USB
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TFT LCD (4.2)
TO AUTO HIGH BEAM IND (DIAGRAM 4 OF 4)
TRANSMISSIONS SYSTEM
USB 2.0 SD/MSPRO CARD READER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 4) -> SPI TO USB
