Kia Soul III facelift (2022-2024) slave gnd Wiring diagram
This page shows the only wiring diagram for the component.slave gnd, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram slave gnd (1 of 1)
'B' OUTPUT
ACC OUTPUT
AMP
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DIAG WIRE
DRIVER DOOR MOOD RANGE LAMP
DRIVER DOOR SPEAKER
FL (-)
FL SPKR (-)
FR (-)
FR SPKER (-)
FR SPKR (-)
GRN WIRE
GROUND
GRY WIRE
M-CAN HIGH
M-CAN LOW
MEMORY POWER
MID SPEAKER
MID SPKR (+)
MID SPKR FL
MOOD LAMP MODULE (CENTER OF DASH)
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER DOOR MOOD RANGE LAMP
PASSENGER DOOR SPEAKER
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
SLAVE GND
SLAVE LIN
SLAVE PCB ACC
SOUND MOOD LAMP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> SLAVE GND
