Kia Soul III facelift (2022-2024) seek seek down up Wiring diagram
This page shows the only wiring diagram for the component.seek seek down up, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seek seek down up (1 of 1)
AGC
AM/FM ANTENNA
AM/FM OUT
AMP
AUDIO
BLK WIRE
BLU WIRE
BPF
BRN WIRE
CALL SEND
CLOCKSPRING
COMBINATION ANTENNA
GNSS ANTENNA
GNSS OUT/B+
GRN WIRE
GRY WIRE
HPF
ILL
LDO
LEFT STEERING WHEEL REMOTE CONTROL SWITCH (AUDIO, BLUETOOTH)
LNA
LPF
MATCHING CIRCUIT
MUTE MODE
NCA WIRE
PNK WIRE
SEEK SEEK DOWN UP
STEERING WHEEL)
VOICE CALL END
VOL VOL
WHT WIRE
Go to component -> Radio circuit, w/o navigation & amplifier (2 of 3) -> SEEK SEEK DOWN UP
