Kia Soul III facelift (2022-2024) right forward parking distance warning sensor Wiring diagram
This page shows the only wiring diagram for the component.right forward parking distance warning sensor, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right forward parking distance warning sensor (1 of 1)
A/C BLOWER MOTOR CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
AUDIO
AUX, USB JACK
BLK WIRE
BLK/GRN WIRE
BRAKE FLUID LEVEL SENSOR
COOLING FAN MOTOR (PWM)
COOLING FAN MOTOR (REG)
DATA LINK CONNECTOR
E/R JUNCTION BLOCK POWER OUTLET RELAY
E/R-C
EXTERNAL BUZZER
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER MOTOR
HOOD SWITCH
HORN
IBU
LEFT FORWARD PARKING DISTANCE WARNING
LEFT FORWARD PARKING DISTANCE WARNING SENSOR (CENTER)
LEFT FRONT FOG LAMP
LEFT HEADLAMP
MDPS UNIT
MIC SHIELD
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PCB BLOCK
PDM (ACC) RELAY
PNK WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT FORWARD PARKING DISTANCE WARNING SENSOR
RIGHT FORWARD PARKING DISTANCE WARNING SENSOR (CENTER)
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR DOOR LOCK ACTUATOR
SMART CRUISE CONTROL RADAR
START STOP BUTTON SWITCH
STOP LAMP SWITCH
W/ AVN
W/ LED
W/ NAVIGATION
W/O NAVIGATION
WASHER LEVEL SENSOR
WASHER MOTOR
WASHER NOZZLE HEATER
Go to component -> Ground distribution circuit (2 of 5) -> RIGHT FORWARD PARKING DISTANCE WARNING SENSOR
