Kia Soul III facelift (2022-2024) right forward parking distance warning Wiring diagram
This page shows the only wiring diagram for the component.right forward parking distance warning, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right forward parking distance warning (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DISTANCE
GRN WIRE
GRY WIRE
HOT IN ON OR START
IBU
ICU JUNCTION BLOCK
ICU-E
ILL
LEFT FORWARD PARKING DISTANCE WARNING
LEFT FORWARD PARKING DISTANCE WARNING (CENTER)
LIN
MODULE 4 FUSE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PARKING
PAS OPT IN
PDW FWD PWR
PDW REV PWR
PDW SENSOR PWR
PDW SW IND
PDW SW MODE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FORWARD PARKING DISTANCE WARNING
RIGHT FORWARD PARKING DISTANCE WARNING (CENTER)
WARNING SWITCH
YEL WIRE
Go to component -> Parking assistant circuit (1 of 2) -> RIGHT FORWARD PARKING DISTANCE WARNING
