Kia Soul III facelift (2022-2024) rear view camera, tailgate release switch Wiring diagram
This page shows the only wiring diagram for the component.rear view camera, tailgate release switch, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear view camera, tailgate release switch (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MOOD RANGE LAMP
DRIVER POWER OUTSIDE MIRROR
DRIVER RECLINING LIMIT SWITCH
DRIVER SAFETY POWER WINDOW MODULE
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SMART KEY OUTSIDE HANDLE
FUEL SENDER, FUEL PUMP MOTOR
ICU-C
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR POWER WINDOW SWITCH
ORG/ WIRE
POWER OUTSIDE MIRROR SWITCH
POWER WINDOW MAIN SWITCH
REAR DEFOGGER
REAR POWER OUTLET
REAR SEAT WARMER MODULE
REAR VIEW CAMERA, TAILGATE RELEASE SWITCH
REAR WIPER MOTOR
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
TAILGATE LATCH
TAILGATE RELEASE SWITCH
W/ AUTO UP/DOWN, SAFETY
W/ DYNAMIC GUIDE CAMERA
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 5) -> REAR VIEW CAMERA, TAILGATE RELEASE SWITCH
