Kia Soul III facelift (2022-2024) pnk pass seat belt bkle sensor Wiring diagram
This page shows the only wiring diagram for the component.pnk pass seat belt bkle sensor, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk pass seat belt bkle sensor (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DRIVER ANCHOR PRETENSIONER
DRIVER CURTAIN AIR BAG
DRIVER SEAT BELT PRETENSIONER
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT PRESSURE SENSOR
DRIVER SIDE IMPACT SENSOR
GRN WIRE
GRY WIRE
ORG/ WIRE
PASSENGER CURTAIN AIR BAG
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT PRESSURE SENSOR
PASSENGER SIDE IMPACT SENSOR
PNK PASS SEAT BELT BKLE SENSOR WIRE
PNK SNSR (-) WIRE
RED WIRE
SNSR
SRS CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> PNK PASS SEAT BELT BKLE SENSOR WIRE
