Kia Soul III facelift (2022-2024) multi-function camera unit Wiring diagram
This page shows the only wiring diagram for the component.multi-function camera unit, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi-function camera unit (1 of 1)
APS 1 GROUND
APS 1 SIGNAL
APS 1 SUPPLY
APS 2 GROUND
APS 2 SIGNAL
APS 2 SUPPLY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE LIGHT SW
BRAKE TEST SW
BRN WIRE
ETC MOTOR, THROTTLE POSITION SENSOR
ETC OUTPUT (+)
GRN WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
LOCAL CAN HIGH
LOCAL CAN LOW
MOTOR
MULTI-FUNCTION CAMERA UNIT
ON/START INPUT
ORG/ WIRE
PCM
PNK WIRE
RED/BLK WIRE
SMART CRUISE CONTROL RADAR
THROTTLE POSITION SENSOR
TPS 1 SIGNAL
TPS 2 SIGNAL
TPS GROUND
TPS SUPPLY
VEHICLE SPEED
W/ LED
W/O LED
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 3) -> MULTI-FUNCTION CAMERA UNIT
