Kia Soul III facelift (2022-2024) left steering wheel remote control switch Wiring diagrams

This page contains all the electrical diagrams for the component. left steering wheel remote control switch, in which he is found in the car Kia Soul III facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left steering wheel remote control switch (1 of 2)

Wiring diagram left steering wheel remote control switch for Kia Soul III facelift (2022-2024) (1 of 2)

Get access

'B' OUTPUT ACC OUTPUT AUDIO BLK WIRE BLU WIRE BRN WIRE CALL SEND CENTER SPEAKER CLOCKSPRING DC-DC CONVERTER DRIVER DOOR TWEETER SPEAKER GRN WIRE GRY WIRE ILL LEFT STEERING WHEEL REMOTE CONTROL SWITCH MEMORY PWR MODE MUTE NCA WIRE ORG/ WIRE PASSENGER DOOR TWEETER SPEAKER PNK WIRE POWER DISTRIBUTION SYSTEM PPL/BLK WIRE PPL/GRN WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE SEEK DOWN SEEK UP STEERING WHEEL) VOICE CALL END VOL DOWN VOL UP WHT WIRE

Go to component -> Navigation circuit, w/ amplifier (2 of 4) -> LEFT STEERING WHEEL REMOTE CONTROL SWITCH

Wiring diagram left steering wheel remote control switch (2 of 2)

Wiring diagram left steering wheel remote control switch for Kia Soul III facelift (2022-2024) (2 of 2)

Get access

Go to component -> Radio circuit, w/ navigation & amplifier (2 of 4) -> LEFT STEERING WHEEL REMOTE CONTROL SWITCH
