Kia Soul III facelift (2022-2024) key solenoid key interlock sw shift lock solenoid output Wiring diagram
This page shows the only wiring diagram for the component.key solenoid key interlock sw shift lock solenoid output, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key solenoid key interlock sw shift lock solenoid output (1 of 1)
ATM SHIFT LEVER
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRAKE LIGHT SW
BRAKE SWITCH FUSE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOWN SHIFT SWITCH
ESC UNIT ESC MODULE
GRN WIRE
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IBU
ICU JUNCTION BLOCK
ICU-B
ICU-E
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
IPS CONTROL MODULE
KEY IN SW OUTPUT
KEY INTERLOCK SOLENOID (W/O SMART KEY)
KEY INTERLOCK SWITCH
KEY SOLENOID KEY INTERLOCK SW SHIFT LOCK SOLENOID OUTPUT
MODULE 1 FUSE
MODULE 3 FUSE
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCM
PNK WIRE
RED WIRE
RIGHT END OF DASH)
SELECT SWITCH
SHIFT LOCK SOLENOID
STOP LAMP SIG
STOP LAMP SW
STOP LAMP SWITCH
STOP LP SW
TRANSMISSIONS SYSTEM
UP SHIFT SWITCH
W/O SMART KEY
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> KEY SOLENOID KEY INTERLOCK SW SHIFT LOCK SOLENOID OUTPUT
