Kia Soul III facelift (2022-2024) k-line immo Wiring diagram
This page shows the only wiring diagram for the component.k-line immo, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram k-line immo (1 of 1)
ANTENNA COIL
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COIL
COMPUTER DATA LINES SYSTEM
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
IBU
ICU JUNCTION BLOCK
ICU-E
ICU-F
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
IMMOBILIZER IND
INSTRUMENT CLUSTER
K-LINE IMMO
M-CAN TRANSCEIVER
MEMORY 1 FUSE
MEMORY PWR
MICOM
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCM
PNK WIRE
PNK/BLK WIRE
RED WIRE
TRANSPONDER
WHT WIRE
YEL WIRE
Go to component -> Immobilizer circuit, w/o smart key system -> K-LINE IMMO
