Kia Soul III facelift (2022-2024) h/lp low lh Wiring diagrams
This page contains all the electrical diagrams for the component. h/lp low lh, in which he is found in the car Kia Soul III facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram h/lp low lh (1 of 2)
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
B/2
B/3
BLK WIRE
BLU WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DEDICATE DRL LH
DRL
DRL HIGH
E/R JUNCTION BLOCK
FOG LP RH FOG LP LH DEDICATE DRL RH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
H/LP HIGH LH
H/LP HIGH RH
H/LP LOW LH
H/LP LOW RH
HDLP LOW SIG
HOT AT ALL TIMES
HOT W/
IBU 1 FUSE
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-D
ICU-E
ICU-F
ICU-G
IPS CONTROL MODULE
LEFT HEADLAMP
LOW TELLTALE
LOW TELLTALE LH
LOW TELLTALE RH
MODULE 1 FUSE
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
PARKING BRAKE SW
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SPOC+
W/ LED
W/O LED
WHT WIRE
YEL WIRE
Go to component -> Autolamps circuit (1 of 2) -> H/LP LOW LH
Wiring diagram h/lp low lh (2 of 2)
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
B/2
B/3
BLK WIRE
BLU WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DEDICATE DRL LH
DRL
E/R JUNCTION BLOCK
FOG LP LH DEDICATE DRL RH FOG LP RH
GRN WIRE
GRY WIRE
H/LP HIGH LH
H/LP HIGH RH
H/LP LOW LH
H/LP LOW RH
HDLP LOW SIG
HOT AT ALL TIMES
HOT W/
IBU 1 FUSE
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-D
ICU-E
ICU-F
ICU-G
IPS CONTROL MODULE
LEFT HEADLAMP
LOW TELLTALE
LOW TELLTALE LH
LOW TELLTALE RH
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
PARKING BRAKE SW
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SPOC+
W/ LED
W/O LED
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit (1 of 2) -> H/LP LOW LH
