Kia Soul III facelift (2022-2024) haz sw ind Wiring diagram
This page shows the only wiring diagram for the component.haz sw ind, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram haz sw ind (1 of 1)
AUTO
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRAKE SW INPUT
BRAKE SWITCH FUSE
BRK LT SW
BRK TEST SW
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DRIVER POWER OUTSIDE MIRROR
ESC UNIT ESC MODULE
GND (BCM)
GRN WIRE
GRY WIRE
HAZ SW
HAZ SW IND
HEADLAMP
HOT AT ALL TIMES
HOT IN ON OR START
IBU
ICU JUNCTION BLOCK
ICU-B
ICU-E
ICU-F
ICU-G
IPS CONTROL MODULE
LT SW SIG
MEMORY PWR
MODULE 1 FUSE
MODULE 3 FUSE
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
ORG/ WIRE
PCM
PNK/BLK WIRE
PWR GND
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
STOP LAMP SWITCH
STOP LP SIG
STOP LP SW
T/SIG LP SW OUT
TURN LAMP
TURN LEFT
TURN LP SIG
TURN RIGHT
W/ EPB
WIP, LT GND
YEL WIRE
Go to component -> Exterior lamps circuit (4 of 4) -> HAZ SW IND
