Kia Soul III facelift (2022-2024) front wiper low backup sig Wiring diagram
This page shows the only wiring diagram for the component.front wiper low backup sig, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front wiper low backup sig (1 of 1)
BLK WIRE
BLU/BLK WIRE
BRN WIRE
E/R-C
FRONT WASHER MOTOR SW POWER
FRONT WASHER SWITCH
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER LOW BACKUP SIG
FRONT WIPER MOTOR
FRONT WIPER SW SIG
GND (BCM)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
ICU JUNCTION BLOCK
ICU-B
ICU-E
INT/VOL SW SIG
MIST
MULTI-FUNCTION SWITCH (STEERING COLUMN ASSEMBLY)
ON INPUT
ORG/ WIRE
PARKING SWITCH
PCB BLOCK
RED WIRE
RED/BRN WIRE
VOL 1 (FAST)
VOL 2
VOL 3
VOL 4
VOL 5 (SLOW)
WASHER FUSE
WIPER FRT 2 FUSE
WIPER LOW SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit (2 of 2) -> FRONT WIPER LOW BACKUP SIG
