Kia Soul III facelift (2022-2024) fog lamp ind wiring diagram
This page shows the only wiring diagram for the component.fog lamp ind, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fog lamp ind wiring diagram (1 of 1)
AJAR SWITCH
AUTO HIGH BEAM IND
BATTERY IND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
C-CAN TRANSCEIVER
CHECK ENGINE IND
DRIVER DOOR LOCK ACTUATOR
EPB IND
ESP IND
ESP OFF IND
FCA (RED) IND WIRE
FCA IND
FOG LAMP IND
FROM PIN 39 (DIAGRAM 1 OF 4)
HBA (WHITE) IND
HIGH BEAM IND
IMMO IND
INSTRUMENT CLUSTER
INTERFACE
LED LAMP IND
LEFT REAR DOOR LOCK ACTUATOR
LEFT TURN IND
LOW BEAM IND
LOW FUEL IND
M-CAN TRANSCEIVER
MASTER IND
MDPS IND
MICOM
OIL PRESSURE IND
PARKING BRAKE IND.
REAR FOG LAMP IND
RHEOSTAT SW DOWN IN
RHEOSTAT SW UP IN
RIGHT TURN IND
SEAT BELT IND
SPEED SEG IND
TACHOMETER SEG IND
TAIL ON IND
TPMS IND
TRIP SW (-) INPUT
Go to component -> Instrument cluster circuit (4 of 4) -> FOG LAMP IND
