Kia Soul III facelift (2022-2024) esc on/off switch Wiring diagram
This page shows the only wiring diagram for the component.esc on/off switch, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram esc on/off switch (1 of 1)
ABS 1 FUSE
ABS 2 FUSE
ABS 3 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
E/R-D
ESC MODULE
ESC ON/OFF SWITCH
ESC UNIT
FL SIG
FL VCC
FR SIG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IBU
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
NCA WIRE
ON/START PWR
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PARKING BRK SW SIG
PCB BLOCK
PNK WIRE
RED WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL SIG
RL VCC
RR SIG
RR VCC
STOP LAMP SW
VBATT
VBATT MTR RLY
W/ SMART KEY
WHEEL SENS OUTPUT (FR) FR VCC
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, w/o epb (1 of 2) -> ESC ON/OFF SWITCH
