Kia Soul III facelift (2022-2024) cooling fan rly ctrl 1 Wiring diagram
This page shows the only wiring diagram for the component.cooling fan rly ctrl 1, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooling fan rly ctrl 1 (1 of 1)
BLK WIRE
BLU WIRE
BRAKE SW
BRN WIRE
BRN/ORG WIRE
CANISTER CLOSE VALVE
CCP-CAN HIGH
CCP-CAN LOW
CCV CTRL
COMPUTER DATA LINES SYSTEM
COOLING FAN RLY CTRL 1
COOLING FAN RLY CTRL 2
COOLING FANS SYSTEM
ENGINE RPM
ENGINE SPD SIG
ESC UNIT ESC MODULE
FUEL SENDER
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HTR
IBU
IGN COIL CTRL CYL 1 IGN COIL CTRL CYL 4
IGN COIL CTRL CYL 2 IGN COIL CTRL CYL 3
IMMO COMM
IMMO DATA LINE
INJ 1 CTRL
ISG START MOTOR CTRL RLY
MEMORY PWR
OCV 3 CTRL
OIL CONTROL VALVE 1 (INTAKE)
OIL CONTROL VALVE 3
ORG/ WIRE
ORG/BLK WIRE
OUTPUT(FR)
P-CAN HIGH
P-CAN LOW
PCM
PCSV CTRL
PNK WIRE
PURGE CONTROL SOLENOID VALVE
RED WIRE
START SIG IN
STARTING/ CHARGING SYSTEM
STOP LAMP SW
VEHICLE SPD
VEHICLE SPEED SIG
VIS CTRL
W/ EPB
W/ IDLE STOP, GO (ISG)
W/ SMART KEY/IMMO
W/O SMART KEY/IMMO
WHEEL SENS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l, engine controls circuit (7 of 7) -> COOLING FAN RLY CTRL 1
