Kia Soul III facelift (2022-2024) ccp-can high Wiring diagrams
This page contains all the electrical diagrams for the component. ccp-can high, in which he is found in the car Kia Soul III facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ccp-can high (1 of 2)
Go to component -> Computer data lines circuit (3 of 3) -> CCP-CAN HIGH
Wiring diagram ccp-can high (2 of 2)
BLK WIRE
BLU WIRE
BRAKE SW
BRN WIRE
BRN/ORG WIRE
CANISTER CLOSE VALVE
CCP-CAN HIGH
CCP-CAN LOW
CCV CTRL
COMPUTER DATA LINES SYSTEM
COOLING FAN RLY CTRL 1
COOLING FAN RLY CTRL 2
COOLING FANS SYSTEM
ENGINE RPM
ENGINE SPD SIG
ESC UNIT ESC MODULE
FUEL SENDER
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HTR
IBU
IGN COIL CTRL CYL 1 IGN COIL CTRL CYL 4
IGN COIL CTRL CYL 2 IGN COIL CTRL CYL 3
IMMO COMM
IMMO DATA LINE
INJ 1 CTRL
ISG START MOTOR CTRL RLY
MEMORY PWR
OCV 3 CTRL
OIL CONTROL VALVE 1 (INTAKE)
OIL CONTROL VALVE 3
ORG/ WIRE
ORG/BLK WIRE
OUTPUT(FR)
P-CAN HIGH
P-CAN LOW
PCM
PCSV CTRL
PNK WIRE
PURGE CONTROL SOLENOID VALVE
RED WIRE
START SIG IN
STARTING/ CHARGING SYSTEM
STOP LAMP SW
VEHICLE SPD
VEHICLE SPEED SIG
VIS CTRL
W/ EPB
W/ IDLE STOP, GO (ISG)
W/ SMART KEY/IMMO
W/O SMART KEY/IMMO
WHEEL SENS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l, engine controls circuit (7 of 7) -> CCP-CAN HIGH
