Kia Soul III facelift (2022-2024) call end wiring diagram
This page shows the only wiring diagram for the component.call end, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
call end wiring diagram (1 of 1)
'B' OUTPUT
ACC OUTPUT
AUDIO
BLK WIRE
BLU WIRE
BRN WIRE
CALL END
CALL SEND
CENTER SPEAKER
CLOCKSPRING
DRIVER DOOR SPEAKER
DRIVER DOOR TWEETER SPEAKER
GRN WIRE
GRY WIRE
ILL
LEFT REAR DOOR SPEAKER
LEFT STEERING WHEEL REMOTE CONTROL SWITCH (AUDIO, BLUETOOTH)
MEMORY PWR
MODE
MUTE
NCA WIRE
ORG/ WIRE
PASSENGER DOOR TWEETER SPEAKER
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/BLK WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
SEEK DOWN
SEEK UP
STEERING WHEEL)
VOICE
VOL (-)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, w/o navigation w/ amplifier (2 of 4) -> CALL END
