Kia Soul III facelift (2022-2024) bcw rh ind Wiring diagram
This page shows the only wiring diagram for the component.bcw rh ind, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bcw rh ind (1 of 1)
BCW IND
BCW LH IND
BCW RH IND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DC-DC
DRIVER POWER OUTSIDE MIRROR
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ICU JUNCTION BLOCK
ICU-C
ICU-E
INSTRUMENT CLUSTER
L-CAN HIGH
L-CAN LOW
LEFT BLIND-SPOT COLLISION WARNING UNIT
MEMORY PWR
MICOM
MODULE 1 FUSE
MODULE 4 FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK/BLK WIRE
RED WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
SIG GND 1
TRANSCEIVER/
WHT WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> BCW RH IND
