Kia Soul III facelift (2022-2024) active vent low Wiring diagram
This page shows the only wiring diagram for the component.active vent low, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram active vent low (1 of 1)
A/BAG IND FUSE
ACTIVE VENT HIGH
ACTIVE VENT LOW
AIR BAG 1 FUSE
AIR BAG 2 FUSE
ALR (-) PNK ALR (+) GROUND WIRE
ALR SENSOR
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT
CRASH UNLOCK
DRIVER AIR BAG
DRIVER SEAT BELT
DRIVER SEAT BELT BUCKLE SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ICU JUNCTION BLOCK
ICU-C
ICU-D
ICU-E
ICU-G
IPS CONTROL MODULE
MEMORY POWER
NCA WIRE
OCCUPANT DETECTION SENSOR
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER AIR BAG (VENT)
PASSENGER AIR BAG 1
PASSENGER AIR BAG 2
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
SRS CONTROL MODULE
STEERING WHEEL)
TELLTALE LAMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> ACTIVE VENT LOW
