Kia Soul III (2019-2024) wpc signal Wiring diagram
This page shows the only wiring diagram for the component.wpc signal, which is found in the car Kia Soul III (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wpc signal (1 of 1)
2.0L
ACC RLY CNTRL
ANT 2 GND
ANT 2 PWR
ANT 3 GND
ANT 3 PWR
BLK WIRE
BLK/GRN WIRE
BLLU
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
BRN/YEL WIRE
BUMPER ANT GND
BUMPER ANT PWR
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
E/R JUNCTION BLOCK (LEFT SIDE OF ENGINE COMPT)
ECM (1.6L TURBO) PCM (2.0L)
EMS COM
ENGINE RPM
EXTERIORS LIGHTS SYSTEM
EXTERNAL BUZZER
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
IBU
ILL
IMMO GROUND
IMMO POWER
KEY INTRLK SW (CVT, DCT) IGN LK SW (M/T)
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PDM 2 (ACC) RELAY
PNK WIRE
RED WIRE
RHEOSTAT
RR WHEEL SENSOR SIG
SIGNAL
SMART KEY ANTENNA 2
SMART KEY ANTENNA 3
SMART KEY BUMPER ANTENNA
SSB
SSB ILL POWER
START F/B SIGNAL
START RLY OUTPUT
START STOP BUTTON SWITCH
STARTING/CHARGING SYSTEM
STOP LAMP SWITCH
SYMBOL
TYEL
VIO WIRE
W/ LOW/HIGH BEAM HEADLIGHT TYPE W/O LOW/HIGH BEAM HEADLIGHT TYPE
WHT WIRE
WIRELESS CHARGER
WPC SIGNAL
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, w/ smart key system (2 of 2) -> WPC SIGNAL
