Kia Soul III (2019-2024) trip sw paddle down Wiring diagrams
This page contains all the electrical diagrams for the component. trip sw paddle down, in which he is found in the car Kia Soul III (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
trip sw paddle down wiring diagram (1 of 2)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
CRUISE SW PADDLE UP
D IND
D OUT
DETENT
DRIVE MODE SW IN
DRIVE MODE SWITCH
DRIVER CONSOLE SWITCH
GRN WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HALL 1
HALL 2
HALL 3
ILL
INSTRUMENT CLUSTER
LT GRN/WHT WIRE
M-CAN TRANSCEIVER
MICOM
N IND
N OUT
ORG/ WIRE
ORG/WHT WIRE
P IND
P OUT
PADDLE SHIFT (DOWN) SWITCH LH
PADDLE SHIFT (UP) SWITCH RH
PNK WIRE
PNK/BLK WIRE
R - OUT
R IND
RED WIRE
RED/YEL WIRE
REMOTE CONTROL SWITCH RH (TRIP/ACC)
S OUT
S(-) IND
SHIFT LEVER INDICATOR
SHIFT MOTOR #1
SHIFT MOTOR #2
SHIFT MOTOR 1 (ODD)
SHIFT MOTOR 2 (EVEN)
STEERING WHEEL)
TRIP
TRIP SW PADDLE DOWN
TRIP SW(-)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> 1.6l turbo, transmission circuit (2 of 3) -> TRIP SW PADDLE DOWN
trip sw paddle down wiring diagram (2 of 2)
2.0L M/T
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
CLOCKSPRING
CRUISE ON/OFF RES+
CRUISE SW PADDLE UP
DC-DC CONVERTER
DRIVE MODE SWITCH
DRIVER CONSOLE SWITCH
ENGINE CONTROL SYSTEM
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-F
ILL
LEFT PADDLE SHIFT (DOWN) SWITCH
MEMORY 1 FUSE
NCA WIRE
NEUTRAL SWITCH
ORG/ WIRE
OUTPUT
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT PADDLE SHIFT (UP) SWITCH
RIGHT STEERING WHEEL REMOTE CONTROL SWITCH
SCC
SET-
SOUND SYSTEM/ NAVIGATION SYSTEM
STEERING WHEEL)
TRIP
TRIP SW PADDLE DOWN
UP DOWN GROUP
VIO WIRE
W/ IDLE STOP-GO
W/O IDLE STOP-GO
YEL WIRE
YEL/BLK WIRE
Go to component -> Instrument cluster circuit (2 of 4) -> TRIP SW PADDLE DOWN
