Kia Soul III (2019-2024) rear heated relay Wiring diagram
This page shows the only wiring diagram for the component.rear heated relay, which is found in the car Kia Soul III (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear heated relay (1 of 1)
A/C CONTROL MODULE
AUTOMATIC A/C MANUAL A/C
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DEF (ACT HI)
DEFOGGER
DRIVER POWER OUTSIDE MIRROR
E/R JUNCTION BLOCK
ECM (1.6L TURBO)
FRT GLASS HTD RLY
GROUND
HEATED GLASS SWITCH
HEATED MIRROR FUSE
HOT AT ALL TIMES
HOT IN ON
HTD GLASS SW IN
HTD NOZZLE OUT
IBU
ICU JUNCTION BLOCK
ICU-B
ICU-C
ICU-E
ICU-F
ICU-G
IND
IPS CONTROL MODULE
MODULE 6 FUSE
MODULE 7 FUSE
MULTI FUSE
OFF
ON INPUT
ON OFF
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
PNK/BLK WIRE
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RR DEF SW IN
RR HTD RLY CTRL
SYSTEM
WASHER NOZZLE HEATER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Defoggers circuit (1 of 2) -> REAR HEATED RELAY
