Kia Soul III (2019-2024) ptc heater 2 relay e/r junction block Wiring diagram
This page shows the only wiring diagram for the component.ptc heater 2 relay e/r junction block, which is found in the car Kia Soul III (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ptc heater 2 relay e/r junction block (1 of 1)
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
ATM SHIFT LEVER INDICATOR
AUDIO
BLK WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
CRASH PAD SWITCH
DC-DC CONVERTER
E/R-C
ELECTRO- CHROMIC MIRROR
FRONT AIR VENTILATION SEAT CONTROL MODULE
FRONT HEATED BOX
FRONT SEAT WARMER CONTROL MODULE
FRONT WIPER (LOW) RELAY
FRONT WIPER MOTOR
GRN WIRE
GRY WIRE
IBU
ICM RELAY BOX
ICU-B
ICU-C
ICU-E
ICU-F
LED
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT FRONT HEATED RELAY
MULTI- FUNCTION SWITCH
MULTI-FUNCTION CAMERA
ORG/ WIRE
PCB BLOCK
PNK PNK WIRE
PNK WIRE
PTC HEATER 1 RELAY
PTC HEATER 2 RELAY E/R JUNCTION BLOCK
REAR SEAT WARMER CONTROL MODULE
REAR WIPER MOTOR
REAR WIPER RELAY
RED WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
SMART CRUISE CONTROL RADAR
W/ AIR VENTIL- ATION
W/ AIR VENTILATION
W/ AUDIO
W/O AIR VENTIL- ATION
W/O AIR VENTILATION
WASHER FUSE
WHT WIRE
WIPER (REAR) FUSE
YEL WIRE
Go to component -> Power distribution circuit (4 of 8) -> PTC HEATER 2 RELAY E/R JUNCTION BLOCK
