Kia Soul III (2019-2024) power outside mirror switch Wiring diagrams
This page contains all the electrical diagrams for the component. power outside mirror switch, in which he is found in the car Kia Soul III (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power outside mirror switch (1 of 3)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/WHT WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MOOD RANGE LAMP
DRIVER POWER OUTSIDE MIRROR
DRIVER RECLINING LIMIT SWITCH
DRIVER SAFETY POWER WINDOW MODULE
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SMART KEY OUTSIDE HANDLE
FUEL SENDER, FUEL PUMP MOTOR
GRN WIRE
ICU-C
LEFT BLINDSPOT COLLISION WARNING UNIT
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR POWER WINDOW SWITCH
NCA WIRE
POWER OUTSIDE MIRROR SWITCH
POWER WINDOW MAIN SWITCH
REAR DEFOGGER
REAR POWER OUTLET
REAR SEAT WARMER MODULE
REAR VIEW CAMERA
REAR WIPER MOTOR
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
TAILGATE LATCH
W/ DYNAMIC GUIDE CAMERA
W/ MIDRANGE SPEAKER
W/0 MIDRANGE SPEAKER
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 6) -> POWER OUTSIDE MIRROR SWITCH
Wiring diagram power outside mirror switch (2 of 3)
A/V, NAVIGATION HEAD UNIT
ACC/ON
AMBER
AMP
AUDIO
BCAN-HI
BCAN-LO
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/ORG WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DRIVER DOOR MOOD RANGE LAMP
FROM ICU JUNCTION BOX (SHORT TERM LOAD) (DIAGRAM 7 OF 8)
FROM IGNITION SWITCH (ACC) (DIAGRAM 1 OF 8)
FROM VACUUM PUMP FUSE (DIAGRAM 1 OF 8)
FRONT USB CHARGER
GREEN
GRN WIRE
GRN/BLU WIRE
GRY WIRE
IBU
ICU-D
ICU-E
ILL
LEFT FRONT POWER OUTLET
MEM PWR
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MOOD RANGE LAMP
PNK WIRE
PNK/WHT WIRE
POWER OUTLET 1 FUSE
POWER OUTLET 2 FUSE
POWER OUTLET 3 FUSE
POWER OUTLET FUSE
POWER OUTLET RELAY
POWER OUTSIDE MIRROR SWITCH
REAR POWER OUTLET
REAR USB CHARGER
RED WIRE
RED/WHT WIRE
RIGHT FRONT POWER OUTLET
SIG
SOUND MOOD LAMP
VIO WIRE
W/ AUDIO
W/ IDLE STOP/GO
W/O IDLE STOP/GO
WHT WIRE
WIRELESS CHARGER
WIRELESS CHARGER INDICATOR
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (3 of 8) -> POWER OUTSIDE MIRROR SWITCH
Wiring diagram power outside mirror switch (3 of 3)
