Kia Soul III (2019-2024) passenger temperature actuator Wiring diagram
This page shows the only wiring diagram for the component.passenger temperature actuator, which is found in the car Kia Soul III (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger temperature actuator (1 of 1)
2.0L, 1.6L TURBO
A/C 1 FUSE
A/C 2 FUSE
A/C COMPRESSOR (LEFT FRONT OF ENGINE)
AUTO LIGHT, PHOTO SENSOR PHOTO SENSOR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
CLUTCH
DRIVER TEMPERATURE ACTUATOR
E/R JUNCTION BLOCK
ELECTRONIC CONTROL VALVE
GRN BLK/ WIRE
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ON
ICU JUNCTION BLOCK
ICU-B
ICU-E
ICU-F
MEMORY 1 FUSE
MODULE 5 FUSE
MULTI FUSE 3
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER TEMPERATURE ACTUATOR
PHOTO SENSOR
PNK WIRE
PTC HEATER (IF EQUIPPED)
PTC HEATER 1
PTC HEATER 1 FUSE
PTC HEATER 1 RELAY
PTC HEATER 2
PTC HEATER 2 FUSE
PTC HEATER 2 RELAY
RED WIRE
RIGHT END OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> PASSENGER TEMPERATURE ACTUATOR
