Kia Soul III (2019-2024) fca off ind Wiring diagrams
This page contains all the electrical diagrams for the component. fca off ind, in which he is found in the car Kia Soul III (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fca off ind (1 of 2)
120 KM/H IND
511 OHM
61.9 OHM 61.9 OHM
ABS IND.
AJAR SWITCH
AUTO STOP (GREEN) IND
AUTO STOP (YELLOW) IND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
C-CAN TRANSCEIVER
CHARGE IND
CHECK ENGINE IND
DIMMING CIRCUIT (GREEN)
DRIVER DOOR LOCK ACTUATOR
ESC IND
ESC OFF IND
FCA OFF IND
FROM PIN 39 (DIAGRAM 4 OF 4)
FROM PIN 40 (DIAGRAM 4 OF 4)
FRONT FOG IND
HBA IND
HEADLAMP FAIL IND
HIGH BEAM IND
IMMO IND
INSTRUMENT CLUSTER
LEFT REAR DOOR LOCK ACTUATOR
LEFT TURN IND
LKAS/LDWS (GREEN) IND
LOW BEAM IND
LOW FUEL IND
LWDS (YELLOW) IND
M-CAN TRANSCEIVER
MASTER WARNING IND
MDPS IND
MICOM
OIL PRESSURE IND
PARKING BRAKE IND.
RIGHT TURN IND
SEAT BELT IND
STANDARD CLUSTER
TAIL ON IND
TPMS IND
TRIP SW(-)
Go to component -> Instrument cluster circuit (4 of 4) -> FCA OFF IND
Wiring diagram fca off ind (2 of 2)
'B' OUTPUT
A/V, NAVIGATION HEAD UNIT
AMP
AUDIO UNIT
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH (LEFT END OF DASH)
DC-DC CONVERTER
DIMMING CIRCUIT (GREEN)
FCA OFF IND
GDC
GRN WIRE
GRY WIRE
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-E
ICU-F
ILL
INSTRUMENT CLUSTER
L-CAN HIGH
L-CAN LOW
LANE KEEPING ASSIST SWITCH
LDWS (YELLOW) IND
LKAS/LDWS (GREEN) IND
M-CAN TRANSCEIVER
MEMORU PWR
MEMORY 1 FUSE
MEMORY PWR
MICOM
MODULE 4 FUSE
MULT- MEDIA FUSE
MULTI-FUNCTION CAMERA
ON/START INPUT
ORG/ WIRE
PNK/BLK WIRE
RED WIRE
REG
RIGHT END OF DASH)
SIGNAL, SWITCH
SMART CRUISE CONTROL RADAR
SPEAKER
TFT LCD
W/ IDLE STOP/GO
W/ NAVIGATION
W/O AMP W/ AMP
W/O IDLE STOP/GO
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Lane keeping assist circuit -> FCA OFF IND
