Kia Soul III (2019-2024) brk lt sw Wiring diagram
This page shows the only wiring diagram for the component.brk lt sw, which is found in the car Kia Soul III (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brk lt sw (1 of 1)
ALTERNATOR FR
APS 1 SIG
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BPS SIG
BRK LT SW
BRK TEST SW
BRN WIRE
BVS/VAC PUMP SIG
CAMSHAFT POSITION SENSOR 1 (INTAKE)
CAMSHAFT POSITION SENSOR 2 (EXHAUST)
CKPS GND
CKPS SIG
CMPS 1 (INTAKE) SIG
CMPS 1 INTAKE GND
CMPS 2 (EXHAUST) SIG
CMPS 2 EXHAUST GND
CRANKSHAFT POSITION SENSOR
DEFOGGER SYSTEM
DEFROST ACTIVE
ECTS SIG
ELECTRIC WASTEGATE ACTUATOR
ETC MTR
EWGA MOTOR (+)
EWGA MTR (-)
EWGA SENS SIG
FPCV (-)
FUEL PRESSURE CONTROL VALVE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
IGN COIL 1 CTRL
IGN COIL 2 CTRL
IGN COIL 3 CTRL
IGN COIL 4 CTRL
INJ 1 CTRL
INJ 2 CTRL
INJ 3 CTRL
INJ 4 CTRL
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
ISG SW
ORG/ WIRE
PNK WIRE
REAR OF CYL HEAD)
RED WIRE
START SW IN
STARTING/CHARGING SYSTEM
TPS 1 SIG
VEH SPD SIG
W/ ISG
W/O ISG
WHT WIRE
WHT/BLK WIRE
WIPER SW IN
WIPER/WASHER SYSTEM
Go to component -> Wiring diagram engine performance 1.6l turbo (1 of 6) -> BRK LT SW
