Kia Soul II facelift (2016-2019) unfolding relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.unfolding relay ctrl, which is found in the car Kia Soul II facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unfolding relay ctrl (1 of 1)
"P" POSITION SW
A/V TAIL OUT
AUTO LIGHT SW
BCM (CENTER OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
DEFOGGER SYSTEM
DOOR UNLOCK SIG
DRL INPUT
FOLDING RELAY CTRL
FOLDING SW SIG
FRONT WIPER WASHER MOTOR
GLASS STATUS SIG/SERIAL
GND PWR
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HEADLAMP HIGH SW INPUT
HEADLAMP LOW SIG
HEADLAMP LOW SW INPUT
HEADLIGHTS SYSTEM
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
ILL
KEY SOLENOID
LEFT DRL OUT
MIRRORS SYSTEM
NCA WIRE
ON INPUT
PASS/BELT IND
POWER TOPS SYSTEM
REAR DEFOGGER SW INPUT
REAR WIPER WASHER MOTOR
RED WIRE
RED/ORG WIRE
RIGHT DRL OUT
ROOM LAMP OUT
SHIFT INTERLOCK SYSTEM
SOUND SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
UNFOLDING RELAY CTRL
UNFOLDING SW SIG
W/O SMART KEY
WHT WIRE
WHT/ORG WIRE
WIPER RELAY (HIGH)
WIPER RELAY (LOW)
WIPER/WASHER SYSTEM
YEL WIRE
YEL/BLK WIRE
Go to component -> Body control module circuit (2 of 2) -> UNFOLDING RELAY CTRL
