Kia Soul II facelift (2016-2019) tailgate open sw Wiring diagrams
This page contains all the electrical diagrams for the component. tailgate open sw, in which he is found in the car Kia Soul II facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tailgate open sw (1 of 2)
BLK WIRE
BLU WIRE
GRN WIRE
GROUND DISTRIBUTION SYSTEM
HOT W/ LEAK CURRENT AUTO CUT DEVICE RELAY ENERGIZED
I/P-A
I/P-B
I/P-C
I/P-F
IOD 1 FUSE
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEFT MAP LAMP
LEFT REAR PERSONAL LAMP
LEFT VANITY LAMP
LUGGAGE LAMP
OFF
ON DOOR
OVERHEAD CONSOLE LAMP
RED WIRE
RED/BLK WIRE
RIGHT MAP LAMP
RIGHT REAR PERSONAL LAMP
RIGHT VANITY LAMP
ROOM LAMP
SMART JUNCTION BLOCK
TAILGATE LATCH
TAILGATE OPEN SW
TAILGATE OPEN SWITCH
TAILGATE ROOM LAMP
W/ LANE DEPARTURE WARNING SYSTEM W/O LANE DEPARTURE WARNING SYSTEM
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> TAILGATE OPEN SW
Wiring diagram tailgate open sw (2 of 2)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BRN WIRE
C-CAN
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
FUEL CAP OPEN IND
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-B
I/P-G I/P-F
INSTRUMENT CLUSTER
IPS CONTROL MODULE
MICOM
MOTOR
NCA WIRE
ORG/ WIRE
PNK WIRE
SIG 1 GND
SMART JUNCTION BLOCK
T/GATE OPEN FUSE
T/GATE OPEN RELAY
TAILGATE HANDLE SW
TAILGATE HANDLE SWITCH
TAILGATE LATCH
TAILGATE OPEN SW
TAILGATE OPEN SWITCH
TAILGATE RLY CTRL
TRANSCEIVER/
TRUNK OPEN IND
WHT WIRE
Go to component -> Tailgate release circuit -> TAILGATE OPEN SW
