Kia Soul II facelift (2016-2019) mod lamp module Wiring diagram
This page shows the only wiring diagram for the component.mod lamp module, which is found in the car Kia Soul II facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mod lamp module (1 of 1)
1.6L
2.0L, 1.6L TURBO
A/C CONTROL MODULE
A/T
AEB UNIT
ATM LEVER INDICATOR
AUTO HEADLAMP LEVELING DEVICE MODULE
AUTOMATIC A/C
BCM
BLK WIRE
BLK/WHT WIRE
CLOCK- SPRING
CLUSTER IONIZER
CONDENSER
DATA LINK CONNECTOR
FET (FIELD EFFECT TRANSISTOR)
FRONT CIGARETTE LIGHTER, POWER OUTLET
FRONT POWER OUTLET
GLOVE BOX LAMP)
HAZARD SWITCH
I/P-F
ICM RELAY BOX
IGNITION COIL 1 SHIELD
IGNITION COIL 2 SHIELD
IGNITION COIL 3 SHIELD
IGNITION COIL 4 SHIELD
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
IMMOBILIZER MODULE
INSTRUMENT CLUSTER
IPS CONTROL MODULE
KNOCK SENSOR SHIELD
LEFT HEADLAMP LEVELING DEVICE ACTUATOR
M/T A/T
MANUAL A/C
MOD LAMP MODULE
MULTI- FUNCTION SWITCH
NCA WIRE
NEUTRAL SWITCH
ORG/ WIRE
OUTSIDE MIRROR FOLDING RELAY
OUTSIDE MIRROR UNFOLDING RELAY
POWER OUTPUT 1 RELAY
POWER OUTPUT 2 RELAY
PWR GND (IPS)
RIGHT HEADLAMP LEVELING DEVICE ACTUATOR
SIG GND (IPS)
SMART JUNCTION BLOCK
SPORT MODE SWITCH
START STOP BUTTON SWITCH
STEERING WHEEL HEATER MODULE
STEERING WHEEL SWITCH
USB CHARGER 1
USB CHARGER 2
W/O SMART KEY
Go to component -> Ground distribution circuit (4 of 5) -> MOD LAMP MODULE
