Kia Soul II facelift (2016-2019) htd whl ind Wiring diagram
This page shows the only wiring diagram for the component.htd whl ind, which is found in the car Kia Soul II facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram htd whl ind (1 of 1)
BLK WIRE
BLU WIRE
CLOCK- SPRING
CRASH PAD SWITCH
GND NTC (+)
GRN WIRE
GRY WIRE
HEATED
HEATED STEERING FUSE
HEATED WHEEL (-)
HEATER PAD
HOT IN ON
HTD WHL IND
I/P-F
ILL
IND
INSTRUMENT CLUSTER
MICOM
NTC-
ORG/ WIRE
RED WIRE
SMART JUNCTION BLOCK
STEERING WHEEL HEATER MODULE
STEERING WHEEL HEATER SWITCH
STEERING WHEEL SWITCH
SWITCH
WHT WIRE
YEL/BLK WIRE
Go to component -> Heated steering wheel circuit -> HTD WHL IND
