Kia Soul II facelift (2016-2019) fan pwm Wiring diagrams
This page contains all the electrical diagrams for the component. fan pwm, in which he is found in the car Kia Soul II facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fan pwm (1 of 3)
A/C PRESSURE TRANSDUCER
APT GND
APT SIG
BLK WIRE
BLK/ORG WIRE
BLOWER MOTOR
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
COOLING FAN 2 RELAY
COOLING FAN CONTROLLER
COOLING FAN FUSE
E/R JUNCTION BLOCK
E/R-B
E/R-C
ECTS GROUND
ECTS SIGNAL
ECU 2 FUSE
ECU 4 FUSE
ECU 5 FUSE
ENGINE CONTROL RELAY
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE CTRL RLY
FAN PWM
GRY WIRE
HOT AT ALL TIMES
MEMORY PWR
MICOM
NCA WIRE
ORG/ WIRE
PCB BLOCK
PNK WIRE
POWER CONDITIONING
RED WIRE
SENSOR 2 FUSE
SR-
TEMP
WHT WIRE
YEL WIRE
Go to component -> 1.6l turbo, automatic a/c circuit (3 of 3) -> FAN PWM
Wiring diagram fan pwm (2 of 3)
A/C PRESSURE TRANSDUCER
APT GND
APT SIG
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
COOLING FAN 2 RELAY
COOLING FAN CONTROLLER
COOLING FAN FUSE
E/R JUNCTION BLOCK
E/R-B
E/R-C
ECTS GROUND
ECTS SIGNAL
ECU 2 FUSE
ECU 4 FUSE
ECU 5 FUSE
ENGINE CONTROL RELAY
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE CTRL RLY
FAN PWM
GRY WIRE
HOT AT ALL TIMES
MEMORY PWR
MICOM
NCA WIRE
ORG/ WIRE
PCB BLOCK
POWER CONDITIONING
RED WIRE
SENSOR 2 FUSE
SR-
TEMP
WHT WIRE
YEL WIRE
Go to component -> 1.6l turbo, cooling fan circuit -> FAN PWM
Wiring diagram fan pwm (3 of 3)
ALTERNATOR PWM OUTPUT
APS 1 GND
APS 2 GND
APS 2 SPLY
APT GND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BPS GND
BRAKE BOOSTER VACUUM PRESSURE SENSOR
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
BVS GND
C-CAN HIGH
C-CAN LOW
CMPS 1 (INTAKE) SENS PWR
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CVVT 1 CTRL (INTAKE)
CVVT 2 CTRL EXHAUST
E/R JUNCTION BLOCK
ECTS GND
ECU 4 FUSE
ECU 5 FUSE
ECU FUSE
ENGINE CTRL RLY ON INPUT
FAN PWM
FTPS GND
FUEL PUMP RLY CTRL CCV CTRL
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
I/P-F
MEMORY POWER
MEMORY PWR
OIL CONTROL VALVE 2 (EXHAUST)
ON/START IN
ON/START INPUT
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RPS GND
SMART JUNCTION BLOCK
START RLY CTRL
STARTING/CHARGING SYSTEM
SWITCH SIG
VACUUM PUMP (LEFT SIDE OF ENGINE)
VACUUM PUMP 1 FUSE
VACUUM PUMP 2 FUSE
W/ SMART KEY, IMMO W/O SMART KEY, IMMO
WASTEGATE VALVE
WGV INPUT
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo (6 of 6) -> FAN PWM
