Kia Soul II facelift (2016-2019) e/r junction block cooling fan 2 relay Wiring diagram
This page shows the only wiring diagram for the component.e/r junction block cooling fan 2 relay, which is found in the car Kia Soul II facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram e/r junction block cooling fan 2 relay (1 of 1)
1.6L
2 STEPS
2.0L
3 STEPS
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BUTTON START (ACC) RELAY
CLUTCH SWITCH
DRIVER AIR VENTILATION SEAT CONTROL MODULE
DRIVER AIR VENTILATION SEAT CUSHION BLOWER MOTOR
DRIVER AIR VENTILATION SEAT WARMER, RECLINING BLOWER MOTOR
DRIVER RECLINING LIMIT SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SEAT WARMER MODULE
E/R JUNCTION BLOCK COOLING FAN 2 RELAY
E/R-B
EXTERNAL BUZZER
FRONT DEICER
FRONT SEAT WARMER MODULE
FRONT WIPER (LOW) RELAY
FRONT WIPER MOTOR
FUEL SENDER, FUEL PUMP MOTOR
GRN WIRE
HIGH MOUNTED STOP LAMP
HORN
I/P-E
IPS CONTROL MODULE
LEFT BLIND SPOT DETECTION RADAR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT REAR COMBINATION LAMP
LEFT REAR DOOR LOCK ACTUATOR
LICENSE LAMP
M/T
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
OPT OPT GND GND (HID) (DRL)
PCB BLOCK
PORTABLE LAMP
REAR POWER OUTLET
REAR SEAT WARMER MODULE
RIGHT BLIND SPOT DETECTION RADAR
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SMART JUNCTION BLOCK
VACUUM PUMP
W/ AIR VENTILATION SEAT
W/ DRIVER POWER SEAT
W/ HID
W/ LED
W/ POWER SEAT
W/ PROJECTION LAMP
W/ SMART KEY
W/O AIR VENTILATION SEAT
W/O DRIVER POWER SEAT
W/O HID
W/O LED
WASHER LEVEL SENSOR
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> E/R JUNCTION BLOCK COOLING FAN 2 RELAY
