Kia Soul II facelift (2016-2019) e/r fuse, relay block Wiring diagram
This page shows the only wiring diagram for the component.e/r fuse, relay block, which is found in the car Kia Soul II facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram e/r fuse, relay block (1 of 1)
4.2 INCH
B+3 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DOT LCD
E/R FUSE, RELAY BLOCK
GROUND
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-D
I/P-F
INSTRUMENT CLUSTER
IOD 4 FUSE
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEAK CURRENT AUTO CUT DEVICE RELAY
LEAK CURRENT AUTO CUT DEVICE RLY CTRL
LEAK CURRENT AUTO CUT DEVICE SWITCH
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MEMORY PWR
MICOM
MODULE 3 FUSE
ON/START I/P
PNK WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SIG 1 GND
SMART JUNCTION BLOCK
TFT
TFT LCD
TIRE PRESSURE MONITORING MODULE
TPMS IND
TRANSCEIVER/
WHT WIRE
Go to component -> Tire pressure monitoring circuit -> E/R FUSE, RELAY BLOCK
