Kia Soul II facelift (2016-2019) c-can hi Wiring diagrams
This page contains all the electrical diagrams for the component. c-can hi, in which he is found in the car Kia Soul II facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
c-can hi wiring diagram (1 of 3)
1.6L
2.0L
A/T M/T
ACC FUSE
ACC/ON INPUT
ANTENNA GND
ANTENNA PWR
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
BUTTON START (ACC) RELAY
C-CAN HI
C-CAN LO
COMPUTER DATA LINES SYSTEM
DRV TOGGLE BUTTON
E/R JUNCTION BLOCK
E/R-B
E/R-C
E/R-D
ECU FUSE
EMS COM
ENGINE RPM SIG
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-F
I/P-G
IG 1 FUSE
IG 2 FUSE
MEMORY PWR
MODULE 5 FUSE
ON INPUT
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
P POSITION SW IGN LOCK SW
PASS TOGGLE BUTTON
PCB BLOCK
PDM 1 FUSE
PDM 2 FUSE
PNK WIRE
PNK/BLK WIRE
PWR
RED WIRE
SMART JUNCTION BLOCK
SMART KEY ANTENNA 1
SMART KEY ANTENNA 2
SMART KEY BUMPER ANTENNA
SMART KEY CONTROL MODULE
START FEEDBACK SIG
START RLY
STARTING/CHARGING SYSTEM
TERMINAL CTRL ACC RLY
WHEEL SPEED
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, w/ smart key system (1 of 3) -> C-CAN HI
c-can hi wiring diagram (2 of 3)
AEB SENSOR (2.0L)
AEB UNIT
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
C-CAN HI
C-CAN LO
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT IN ON OR START
I/P-F
ILL
INSTRUMENT CLUSTER
LDWS CAMERA MODULE
LDWS IN
LDWS SWITCH
LOCAL-CAN HI
LOCAL-CAN LO
MICOM
MODULE 3 FUSE
ON/START INPUT
ORG/ WIRE
PNK WIRE
RED WIRE
SIG 1 GND
SMART JUNCTION BLOCK
TRANSCEIVER/
WHT WIRE
Go to component -> Lane departure warning circuit -> C-CAN HI
c-can hi wiring diagram (3 of 3)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HI
C-CAN LO
CKPS GND
CKPS SIG
CMPS 1 GND
CMPS 1 SIG
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
E/R-B
E/R-C
ECU 2 FUSE
ECU 3 FUSE
ENG CTRL RLY
ENGINE CONTROL RELAY
ENGINE RPM OUTPUT
FUEL PUMP FUSE
FUEL PUMP MOTOR
FUEL PUMP RELAY
FUEL SENDER
FUEL SENDER, FUEL PUMP MOTOR
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
IGN COIL CTRL 3
IGN COIL CTRL 4
IGN COIL FUSE
IMMO COMM LINE
INPUT
INSTRUMENT CLUSTER SYSTEM
LAMP SIG
LAMP SW
LIN-COMM
LINES SYSTEM
ON START/INPUT
ORG/BLK WIRE
PCB BLOCK
PCM
PNK WIRE
RED WIRE
SENSOR 1 FUSE
START RLY CTRL
START SW INPUT
STARTING/CHARGING
STARTING/CHARGING SYSTEM
STOP
STOP SIGNAL ELECTRONIC MODULE
SYSTEM
VEHICLE SPD INPUT
VISV CTRL
W/O IMMO/SMART KEY W/ IMMO/SMART KEY
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 2.0l (4 of 6) -> C-CAN HI
