Kia Soul II facelift (2016-2019) bsd on/off switch Wiring diagram
This page shows the only wiring diagram for the component.bsd on/off switch, which is found in the car Kia Soul II facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bsd on/off switch (1 of 1)
BLK WIRE
BLU WIRE
BRN/ORG WIRE
BSD IND
BSD ON/OFF SWITCH
BSD SWITCH
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
GRN WIRE
GRY WIRE
HOT IN ON OR START
I/P-C
ILL
LEFT BLIND SPOT DETECTION RADAR
LOCAL CAN HIGH
LOCAL CAN LOW
MODULE 3 FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RIGHT BLIND SPOT DETECTION RADAR
SMART JUNCTION BLOCK
STATUS IND (ON/OFF SWITCH)
YEL WIRE
Go to component -> Blind spot information system circuit -> BSD ON/OFF SWITCH
