Kia Soul II facelift (2016-2019) alternator pwm output Wiring diagrams
This page contains all the electrical diagrams for the component. alternator pwm output, in which he is found in the car Kia Soul II facelift (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
alternator pwm output wiring diagram (1 of 3)
ALTERNATOR PWM OUTPUT
APS 1 GND
APS 2 GND
APT GND
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
C-CAN TRANSCEIVER
CCV CTRL
CHECK IND
CMPS 1 INTAKE GND
CMPS 2 EXHAUST GND
COMPUTER DATA LINES SYSTEM
DOT LCD, ANALOG
E/R JUNCTION BLOCK
ECTS GND
ECU 4 FUSE
ECU 5 FUSE
ENG CTRL RLY ON I/P
ENGINE
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE CTRL RLY CTRL
ETC MOTOR, +/-
FTPS GND
FUEL
FUEL PUMP MOTOR
FUEL PUMP RLY CTRL
FUEL SENDER
GND MEMORY PWR
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BLK WIRE
HOT AT ALL TIMES
IGN
IGNITION COIL CTRL 2
INSTRUMENT CLUSTER
MEMORY PWR
MICOM
ORG/ WIRE
PCM
PNK WIRE
RED WIRE
RPS GND
SENDER
SIG 1 GND
START RLY CTRL
STARTING/CHARGING SYSTEM
TPS GND
WHT WIRE
Go to component -> Wiring diagram engine performance 1.6l, a/t (7 of 7) -> ALTERNATOR PWM OUTPUT
alternator pwm output wiring diagram (2 of 3)
ACCEL PEDAL POSITION SENSOR
ALTERNATOR PWM OUTPUT
APS 1 GND
APS 2 GND
APS 2 SPLY
APT GND
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
C/FAN RLY CTRL (HIGH) FUEL PUMP RLY CTRL CCV CTRL
C/FAN RLY CTRL LOW
CMPS 1 (INTAKE) SENS PWR
COOLING FANS SYSTEM
CVVT 1 CTRL (INTAKE)
CVVT 2 CTRL EXHAUST
E/R JUNCTION BLOCK
ECTS GND
ECU 4 FUSE
ECU 5 FUSE
ECU FUSE
ENGINE CTRL RLY ON INPUT
FTPS GND
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
MEMORY PWR
OIL CONTROL VALVE 2 (EXHAUST)
ON/START INPUT
ORG/ WIRE
PNK WIRE
RED WIRE
RPS GND
SMART JUNCTION BLOCK
START RLY CTRL
STARTING/CHARGING SYSTEM
VISV CTRL
W/ SMART KEY, IMMO W/O SMART KEY, IMMO
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l, m/t (6 of 6) -> ALTERNATOR PWM OUTPUT
alternator pwm output wiring diagram (3 of 3)
ALTERNATOR PWM OUTPUT
APS 1 GND
APS 2 GND
APS 2 SPLY
APT GND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BPS GND
BRAKE BOOSTER VACUUM PRESSURE SENSOR
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
BVS GND
C-CAN HIGH
C-CAN LOW
CMPS 1 (INTAKE) SENS PWR
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CVVT 1 CTRL (INTAKE)
CVVT 2 CTRL EXHAUST
E/R JUNCTION BLOCK
ECTS GND
ECU 4 FUSE
ECU 5 FUSE
ECU FUSE
ENGINE CTRL RLY ON INPUT
FAN PWM
FTPS GND
FUEL PUMP RLY CTRL CCV CTRL
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
I/P-F
MEMORY POWER
MEMORY PWR
OIL CONTROL VALVE 2 (EXHAUST)
ON/START IN
ON/START INPUT
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RPS GND
SMART JUNCTION BLOCK
START RLY CTRL
STARTING/CHARGING SYSTEM
SWITCH SIG
VACUUM PUMP (LEFT SIDE OF ENGINE)
VACUUM PUMP 1 FUSE
VACUUM PUMP 2 FUSE
W/ SMART KEY, IMMO W/O SMART KEY, IMMO
WASTEGATE VALVE
WGV INPUT
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo (6 of 6) -> ALTERNATOR PWM OUTPUT
