Tailgate release circuit for Kia Soul II (2013-2016)
Tailgate release circuit
B-CAN
B-CAN HIGH LOW
BLK WIRE
BRN WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
FUEL CAP OPEN IND (W/ DOT LCD)
GRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-B
I/P-F
I/P-G
INSTRUMENT CLUSTER
IPS CONTROL MODULE
MICOM
NCA WIRE
ORG/ WIRE
PNK WIRE
PTC TAIL GATE OPEN MOTOR SWITCH
SIG 1 GND
SMART JUNCTION BOX (LEFT END OF DASH)
T/GATE OPEN FUSE
T/GATE OPEN RELAY
TAIL GATE HANDLE SW
TAIL GATE OPEN SW
TAIL GATE RLY CTRL
TAIL- GATE HANDLE SWITCH
TAILGATE LATCH (BOTTOM CENTER OF TAILGATE)
TRUNK OPEN IND
WHT WIRE
