Cooling fan circuit for Kia Soul II (2013-2016)
Cooling fan circuit
1.6L
1.6L 1.6L M/T A/T
2.0L
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
C/FAN 1 RELAY
C/FAN 2 RELAY
C/FAN FUSE
C/FAN HIGH RLY CTRL
C/FAN LOW RLY CTRL
COMPUTER DATA LINE SYSTEM
COOLING FAN MOTOR (BEHIND RADIATOR)
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
E/R JUNCTION BOX
E/R-B
E/R-C
ECT GROUND
ECT SIGNAL
ECU 2 FUSE
ENGINE CONTROL
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
ENGINE CTRL RLY
HOT AT ALL TIMES
NCA WIRE
ORG/ WIRE
PCM (A/T) ECM (M/T) (LEFT REAR OF ENGINE COMPT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY
SENSOR 2 FUSE
WHT WIRE
