Kia Soul II (2013-2016) tail gate rear handle defogger switch Wiring diagram
This page shows the only wiring diagram for the component.tail gate rear handle defogger switch, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail gate rear handle defogger switch (1 of 1)
1.6L
24 24 (W/ UVO) (W/O UVO)
A/V, NAVIGATION HEAD UNIT
AUDIO
AUX JACK
BATTERY, BATTERY FUSE BOX BATTERY
BLK WIRE
CENTER FASCIA SWITCH
COOLING FAN MOTOR
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER PASSENGER SEAT BELT WEIGHT BUCKLE CLASSIFICATION SWITCH SENSOR
E/R-B
ELECTROCHROMIC MIRROR
I/P-F
LEFT REAR PERSONAL LAMP
LEFT VANITY LAMP
MIC SHIELD
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE
OVERHEAD CONSOLE LAMP
REAR WIPER MOTOR
RIGHT HEADLAMP
RIGHT REAR COMBINATION LAMP
RIGHT REAR PERSONAL LAMP
RIGHT VANITY LAMP
ROOM LAMP
SMART KEY AUX, CONTROL USB MODULE JACK
SRS CONTROL MODULE
STOP SIGNAL ELECTRONIC MODULE
SUNROOF SWITCH
TAIL GATE LATCH
TAIL GATE REAR HANDLE DEFOGGER SWITCH
TIRE PRESSURE MONITORING MODULE
TWO TURN UNLOCK RELAY
W/ NAVIGATION
W/ SUNROOF
W/ UVO, NAVIGATION
W/ W/O LED LED
W/O NAVIGATION
W/O SUNROOF
W/O UVO, NAVIGATION
Go to component -> Ground distribution circuit (1 of 4) -> TAIL GATE REAR HANDLE DEFOGGER SWITCH
