Kia Soul II (2013-2016) starting/ cooling charging fans system system Wiring diagram
This page shows the only wiring diagram for the component.starting/ cooling charging fans system system, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starting/ cooling charging fans system system (1 of 1)
1 2 PNK WIRE
ALT PWM O/P
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C/FAN RLY CTRL LOW
DEFOGGER SYSTEM
DEFROST
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
ENGINE RPM O/P
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
INJECTOR 1
INJECTOR 2 INJECTOR 4
INJECTOR 3
KNOCK SENSOR (LOWER LEFT SIDE OF ENGINE BLOCK)
MAP SENSOR (INTAKE MANIFOLD)
ORG BLK WIRE
ORG/ WIRE
PNK 10 11 12 13 14 15 16 17 WIRE
PNK 24 25 26 WIRE
PNK WIRE
RAIL PRESSURE SENSOR (ON FUEL RAIL ASSEMBLY)
RED WIRE
STARTING/ COOLING CHARGING FANS SYSTEM SYSTEM
VISV CTRL
WHT WIRE
Go to component -> Wiring diagram engine performance 1.6l, mfi control circuit, m/t (3 of 6) -> STARTING/ COOLING CHARGING FANS SYSTEM SYSTEM
