Kia Soul II (2013-2016) shift lck sol out Wiring diagram

1.6L A/T 1.6L M/T 10 11 B-CAN HIGH B-CAN LOW 2.0L A/T M/T B-CAN HIGH B-CAN LOW BCM (CENTER OF DASH) BLK WIRE BLU WIRE BRAKE LT SW BRAKE SW 2 FUSE COMPUTER DATA LINES SYSTEM ESC MODULE (LOWER RIGHT REAR OF ENGINE COMPT) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-E I/P-F I/P-G IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH JOINT CONNECTOR KEY IN SW KEY SOL KEY SOLENOID (W/O SMART KEY) (TOP OF STEERING COLUMN) MODULE 1 FUSE MODULE 7 FUSE NCA WIRE ON/START INPUT ORG/ WIRE P POSITION P POSITION SWITCH PCM (A/T) ECM (M/T) (LEFT REAR OF ENGINE COMPT) PNK WIRE PNK/BLK WIRE RED WIRE SELECT SWITCH SHIFT LCK SOL OUT SHIFT LOCK SOLENOID SMART JUNCTION BOX (LEFT END OF DASH) SMART KEY CONTROL MODULE SPORT MODE STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) STOP SIGNAL ELECTRONIC MODULE (LEFT SIDE OF DASH) STP LMP SIG STP LMP SW SWITCH TRANSMISSIONS SYSTEM UP DOWN SHIFT SHIFT W/ SMART KEY W/O SMART KEY WHT/ORG WIRE YEL WIRE YEL/BLK WIRE
