Kia Soul II (2013-2016) rear wiper switch int rear wiper switch on rear washer sw Wiring diagram
This page shows the only wiring diagram for the component.rear wiper switch int rear wiper switch on rear washer sw, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear wiper switch int rear wiper switch on rear washer sw (1 of 1)
B-CAN B-CAN HIGH LOW
B-CAN HIGH B-CAN LOW
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
HOT IN ON
I/P-C
I/P-G
IPS CONTROL MODULE
MULTI- FUNCTION SWITCH
ORG/ WIRE
PARKING SWITCH
PNK/BLK WIRE
REAR INT WIPER SWITCH ON OFF
REAR OFF WASHER ON SWITCH
REAR WIPER MOTOR (CENTER OF TAILGATE DOOR)
REAR WIPER RELAY
REAR WIPER RLY
REAR WIPER SWITCH INT REAR WIPER SWITCH ON REAR WASHER SW
SMART JUNCTION BOX (LEFT END OF DASH)
WHT WIRE
WIPER RR FUSE
YEL/BLK WIRE
