Kia Soul II (2013-2016) passenger passenger power power window window switch switch Wiring diagram
This page shows the only wiring diagram for the component.passenger passenger power power window window switch switch, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger passenger power power window window switch switch (1 of 1)
A/C CONTROL MODULE
A/V, NAVIGATION HEAD UNIT
ATM LEVER INDICATOR
AUDIO
AUTOMATIC A/C
BLU WIRE
CENTER FASCIA SWITCH
CLOCKSPRING (TOP OF STEERING COLUMN)
CONTROL
CRASH AUX, AUX PAD USB JACK SWITCH JACK
DRIVER DOOR MOOD LAMP
FROM LEAK CURRENT AUTOCUT DEVICE RELAY (DIAGRAM 8 OF 10)
GRN WIRE
HAZARD SWITCH
I/P-C
I/P-F
INSTRUMENT CLUSTER
IPS CONTROL MODULE
JOINT CONNECTOR
LEFT REAR POWER WINDOW SWITCH
MANUAL A/C
MOOD LAMP SWITCH
ORG/ WIRE
PASSENGER DOOR MOOD LAMP
PASSENGER PASSENGER POWER POWER WINDOW WINDOW SWITCH SWITCH
POWER POWER WINDOW WINDOW MAIN MAIN SWITCH SWITCH
RIGHT REAR POWER WINDOW SWITCH
STEERING WHEEL)
W/ AUTO UP/DOWN POWER WINDOW W/O AUTO UP/DOWN POWER WINDOW
W/ NAVIGATION
W/ REAR SEAT WARMER
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
W/ UVO
W/O NAVIGATION
W/O REAR SEAT WARMER
W/O UVO
W/O W/ NAVIGATION, NAVIGATION, UVO UVO
YEL WIRE
Go to component -> Power distribution circuit (4 of 10) -> PASSENGER PASSENGER POWER POWER WINDOW WINDOW SWITCH SWITCH
