Kia Soul II (2013-2016) module 5 fuse fuse Wiring diagram
This page shows the only wiring diagram for the component.module 5 fuse fuse, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram module 5 fuse fuse (1 of 1)
2.0L
A/T M/T
ACC RELAY
B-CAN HI B-CAN LO ACC/ON INPUT ON INPUT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
BUTTON
C-CAN LO C-CAN HI
COMPUTER DATA LINES SYSTEM
E/R FUSE, RELAY BOX (LEFT SIDE OF
E/R JUNCTION BOX
E/R-B
E/R-C
E/R-D
ELECTRONIC STEERING COLUMN LOCK COM EMS COM
ELECTRONIC STEERING COLUMN LOCK GND GND GND
ENGINE RPM SIG
FUSE
FUSE ENGINE COMPT)
GND PWR
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-F
I/P-G
MODULE 5 FUSE FUSE
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
PASS TOGGLE BUTTON DRIV TOGGLE BUTTON
PDM 1 FUSE
PDM 2 FUSE ECU FUSE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY
SMART JUNCTION BOX (LEFT END OF DASH)
SMART KEY ANTENNA 1 (UNDER FLOOR CONSOLE)
SMART KEY ANTENNA 2 (UNDER CENTER OF REAR SEAT)
SMART KEY BUMPER ANTENNA (BEHIND CENTER OF REAR BUMPER)
SMART KEY CONTROL MODULE (LEFT END OF DASH)
STARTING/CHARGING SYSTEM
WHEEL SPEED "P" POSITION SW IGN LK SW
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, with smart key system (1 of 3) -> MODULE 5 FUSE FUSE
