Kia Soul II (2013-2016) local can high wiring diagram
This page shows the only wiring diagram for the component.local can high, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
local can high wiring diagram (1 of 1)
AIR BAG IND
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN TRANSCEIVER
CENTER FASCIA SWITCH
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT IMPACT SENSOR (LEFT FRONT OF ENGINE COMPT)
DRIVER SEAT BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY)
ESC MODULE (LOWER RIGHT REAR OF ENGINE COMPT)
GRN WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER
J/C
LOCAL CAN HIGH
LOCAL CAN LOW
MICOM
ORG/ WIRE
ORG/BLK WIRE
PASSENGER AIR BAG 3
PASSENGER AIR BAG IND
PASSENGER FRONT IMPACT SENSOR (RIGHT FRONT OF ENGINE COMPT)
PNK WIRE
PNK/BLK WIRE
RED WIRE
S GND
SBR
SEAT BELT IND
SMART JUNCTION BOX (LEFT END OF DASH)
TAIL LAMP
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> LOCAL CAN HIGH
