Kia Soul II (2013-2016) leak current iod 2 fuse autocut device Wiring diagram
This page shows the only wiring diagram for the component.leak current iod 2 fuse autocut device, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leak current iod 2 fuse autocut device (1 of 1)
ACC/ON INPUT
AUDIO A/V, NAVIGATION HEAD UNIT
BLK WIRE
BLU WIRE
CLOCK
FUSE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
I/P-F
ILL
LCD
LEAK CURRENT IOD 2 FUSE AUTOCUT DEVICE
MEMORY PWR
ORG (OR BLU) WIRE
ORG/ WIRE
SMART JUNCTION BOX (LEFT END OF DASH)
W/ NAVIGATION
W/O NAVIGATION
W/O NAVIGATION W/ UVO
W/O NAVIGATION, UVO
Go to component -> Clock circuit -> LEAK CURRENT IOD 2 FUSE AUTOCUT DEVICE
